Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Evrokod 3: Projektiranje jeklenih konstrukcij - 3-1. del: Stolpi, jambori in dimniki - Stolpi in jamboriEurocode 3 - Bemessung und Konstruktion von Stahlbauten - Teil 3-1: Türme, Maste und Schornsteine - Türme und MasteEurocode 3 - Calcul des structures en acier - Partie 3-1: Tours, mâts et cheminées - Pylônes et mâts haubanésEurocode 3 - Design of steel structures - Part 3-1: Towers, masts and chimneys - Towers and masts91.080.10Kovinske konstrukcijeMetal structures91.010.30Technical aspectsICS:Ta slovenski standard je istoveten z:EN 1993-3-1:2006/AC:2009SIST EN 1993-3-1:2007/AC:2009en,de01-oktober-2009SIST EN 1993-3-1:2007/AC:2009SLOVENSKI

STANDARD
SIST EN 1993-3-1:2007/AC:2009
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1993-3-1:2006/AC
July 2009
Juillet 2009

Juli 2009 ICS 91.010.30; 91.080.10 English version Version Française Deutsche Fassung

Eurocode 3 - Design of steel structures - Part 3-1: Towers, masts and chimneys - Towers and masts

Eurocode 3 - Calcul des structures en acier - Partie 3-1: Tours, mâts et cheminées - Pylônes et mâts haubanés

Eurocode 3 - Bemessung und Konstruktion von Stahlbauten - Teil 3-1: Türme, Maste und Schornsteine - Türme und Maste This corrigendum becomes effective on 1 July 2009 for incorporation in the three official language versions of the EN.

Ce corrigendum prendra effet le 1 juillet 2009 pour incorporation dans les trois versions linguistiques officielles de la EN.

Die Berichtigung tritt am 1.Juli 2009 zur Einarbeitung in die drei offiziellen Sprachfassungen der EN in Kraft.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,

B-1000 Brussels © 2009 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Tous droits d'exploitation sous quelque forme et de quelque manière que ce soit réservés dans le monde entier aux membres nationaux du CEN. Alle Rechte der Verwertung, gleich in welcher Form und in welchem Verfahren, sind weltweit den nationalen Mitgliedern von CEN vorbehalten. Ref. No.:EN 1993-3-1:2006/AC:2009 D/E/FSIST EN 1993-3-1:2007/AC:2009

EN 1993-3-1:2006/AC:2009 (E) 2 1) Modifications to "National Annex for EN 1993-3-1" 2nd paragraph, list, delete the line:

B.2.3(3)". 2nd paragraph, list, replace
"D.1.1(1)"
with

"D.1.1(2)". 2) Modification to 1.1.2 Paragraph "(1)", replace "Provisions for self-supporting and guyed cylindrical towers" with "Provisions for self-supporting and guyed cylindrical and conical towers". 3) Modification to 1.5.12 Replace "(See Annex A and Annex B.)" with "(See Annex B.)". 4) Modification to 2.3.2 Paragraph "(1)", "NOTE", replace "for actions on towers and masts" with "for wind and ice on towers and masts". 5) Modification to 6.2.2 Paragraph "(1)", replace "given in 3.10.3 of EN 1993-1-8 (if bolted) or 4.13 (if welded)" with "given in EN 1993-1-8 clauses 3.10.3 (if bolted) or 4.13 (if welded)". 6) Modifications to 6.4.2 Paragraph "(2)", replace "Figure 6.1" with the following one: "". Paragraph "(2)", delete the last sentence from the "NOTE". SIST EN 1993-3-1:2007/AC:2009

EN 1993-3-1:2006/AC:2009 (E) 3 7) Modification to Clause 8 Paragraph "(2)", "NOTE", replace "given in Annex C to EN 1993-3-2" with "given in Annex D of EN 1993-3-2". 8) Modification to 9.2.1 Paragraph "(1)", replace the whole paragraph "(1)" including the "NOTE" with the following text: "(1)

Fatigue loading of lattice towers due to in-line vibrations (without cross-wind vibrations) induced by gusty wind need not be determined. NOTE:

For guyed masts provided that the detail category of the structural details are greater than 71 N/mm2, the fatigue life of these structures subject to in-line vibrations only (without cross-wind vibrations) induced by gusty wind may be assumed to be greater than 50 years.". 9) Modifications to B.2.1.3 Paragraph "(1)", 1st line, replace "fc" with "∑fc". Paragraph "(1)", Equation "(B.1)", replace "fc" with "∑fc". 10) Modifications to B.2.2.1 Paragraph "(1)", replace "fc" with ",fSc". Paragraph "(1)", replace equation "(B.2)" with ",,,0SfSfSAcKcAθ=⋅⋅∑". Paragraph "(1)", list under "where:...", add the following elements: "AS

is the total area projected normal to the face of the structural components, including those ancillaries treated as structural elements, of the considered face within one section height at the level concerned (see Figure B.2.1) and including icing where appropriate; A

is taken as Aref in 5.3(2) of EN 1991-1-4 and can be taken as any notional value (say unity) as long as Aref is taken as the same value.". Paragraph "(6)", "Figure B.2.2", replace the figure with the following on

...
