SIST EN IEC 60335-2-82:2026
(Main)Household and similar electrical appliances - Safety - Part 2-82: Particular requirements for amusement machines and personal service machines (IEC 60335-2-82:2024)
- Abstract
This European standard deals with the safety of electric commercial amusement machines and personal service machines, their rated voltage being not more than 250 V for single-phase appliances and 480 V for other appliances, including direct current (DC) supplied appliances and battery-operated appliances
- Status
- Published
- Public Enquiry End Date
- 30-Jan-2026
- Publication Date
- 22-Sep-2026
- Technical Committee
- VGA - Safety of household and similar electrical appliances
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 10-Sep-2026
- Due Date
- 15-Nov-2026
- Completion Date
- 23-Sep-2026
SIST EN IEC 60335-2-82:2026 is a CENELEC European Standard for the safety of electric commercial amusement machines and personal service machines. It covers appliances up to 250 V for single-phase supplies and 480 V for other supplies, including DC-supplied and battery-operated appliances, and sets particular requirements for design, construction, marking and testing. Manufacturers, test laboratories, installers, maintenance personnel and buyers use it to judge whether these machines manage electrical, thermal, mechanical and moisture hazards in normal use and foreseeable fault conditions.
What does SIST EN IEC 60335-2-82:2026 specify?
SIST EN IEC 60335-2-82:2026 specifies particular safety requirements for amusement machines and personal service machines and is used together with the general rules in IEC 60335-1. The standard applies to the hazards encountered by users and maintenance persons, and it supplements or modifies the corresponding Part 1 clauses where needed.
Typical amusement machines named in the scope include billiard tables, bowling machines, dartboards, driving simulators, gaming machines, kiddie rides, laser shooting appliances, pinball machines and video games. Typical personal service machines include card re-value machines, currency dispensers, luggage lockers, weighing machines and shoe shining appliances.
The scope excludes several product groups, including:
- appliances intended exclusively for household use
- appliances intended exclusively for industrial purposes
- appliances for use in corrosive or explosive atmospheres
- appliances for washing cars
- dispensing appliances and vending machines
- appliances within the scope of IEC 62368-1, such as jukeboxes, household video games, copying machines, ticket machines and automatic teller machines
- appliances intended to be used when a trained attendant is present, such as virtual reality systems
- equipment intended exclusively for fairgrounds, such as carousels
- self-balancing personal transport devices
The document is organised into clauses 1 to 32, with normative Annex B on battery-operated appliances and normative Annex R on software evaluation. It also includes Figure 101 and Table 101 for the temperature-rise test.
| Annex | What it covers |
|---|---|
| Annex B | Battery-operated appliances, separable batteries and detachable batteries for battery-operated appliances |
| Annex R | Software evaluation for programmable electronic circuits |
What are the key requirements of SIST EN IEC 60335-2-82:2026?
SIST EN IEC 60335-2-82:2026 uses the Part 1 safety framework, then adds product-specific requirements where amusement and personal service machines create different risks. The most practical points are the enclosure rating, access control, temperature limits, moisture resistance, abnormal-operation testing and construction details that affect maintenance and user safety.
Supply, classification and marking
SIST EN IEC 60335-2-82:2026 requires appliances to be class I, class II or class III. Outdoor appliances must be at least IPX4, while appliances cleaned by water jets, or installed where water jets are likely, must be at least IPX5; appliances that use water jets in normal use also need at least IPX5 unless the jet cannot reach the electrical enclosure.
For appliances with a socket outlet, the voltage, nature of supply and current or power output must be marked near the outlet. The installation instructions must say whether the appliance is suitable for outdoor use, warn against water-jet cleaning where IPX5 is not met, and for moving ride appliances give the free space needed around the machine.
Access, guarding and mechanical safety
SIST EN IEC 60335-2-82:2026 adds access checks using test probe 18 and test probe 19 of IEC 61032 for low parts and for kiddie rides. These probes are applied only to surfaces in the user area, which matters because the document treats user access more strictly than maintenance-area access.
Moving parts with kinetic energy above 4 J need interlocked covers unless removal requires a tool. For kiddie rides, seats cannot be adjustable above 1.5 m, and adjustable-seat rides need passenger restraining means such as hand holds, foot wells, seat belts or lap bars.
Heating, surface temperatures and moisture
SIST EN IEC 60335-2-82:2026 introduces a surface-temperature test using Figure 101 and Table 101. The probe is applied with a force of 4 N ± 1 N for 30 s, so designers need to control accessible hot surfaces, not just internal temperatures.
The moisture tests include spillage solution on surfaces and into openings below 2 m, plus repeated liquid-use maintenance operations and wiping tests on cleanable parts. In practice, this means coin slots, control openings, cup-support surfaces and other reachable areas must tolerate realistic liquid exposure without creating a shock or fire hazard.
Abnormal operation and software-controlled functions
SIST EN IEC 60335-2-82:2026 requires testing under fault conditions and unexpected user or maintenance errors, including blocked coin or prize channels, open circuits, incorrect loading and incorrect operation of controls. Detachable parts in the user area are removed or positioned unfavourably, and containers are filled to the worst credible level.
For programmable electronic circuits, the standard checks that simultaneous activation of heaters and motors does not make the appliance unsafe. Annex R is used for software evaluation when fault or error detection and safe shutdown are needed to keep Clause 19 or Clause 22.105 compliant.
Construction, wiring and maintenance access
SIST EN IEC 60335-2-82:2026 gives specific construction rules for interlocks, thermal cut-outs, coin boxes, wiring and service access. Interlocks needed for compliance cannot be defeated without an override key, thermal cut-outs cannot be reset from the user area, and the service area must not be reachable using only the maintenance access key.
Internal wiring that is moved in maintenance needs stronger flexing checks, and wiring anchorages replaced by a maintenance person have extra separation and insulation conditions. Outdoor supply cords must use polychloroprene sheath types suited to the installation method, and outdoor appliances are also checked by the salt mist test of IEC 60068-2-52.
What terms does SIST EN IEC 60335-2-82:2026 define?
SIST EN IEC 60335-2-82:2026 defines several access and maintenance terms that are central to the safety tests.
- access key - a key or other means that gives access to the maintenance area but not to the service area.
- override key - a key or other means used to render an interlock inoperative.
- user area - an area that can be accessed without an access key or tool.
- maintenance area - an area that can be accessed only with an access key.
- service area - an area that cannot be accessed by an access key alone.
- maintenance operation - an operation the user or maintenance person is intended to perform according to the instructions for use, maintenance instructions or appliance marking.
- ready mode - the mode in which the appliance is energised and ready for use, filled as intended but with empty cash boxes.
- kiddie ride - a moving appliance with a stationary base for use by one or two children between three and ten years old under adult supervision.
Who uses SIST EN IEC 60335-2-82:2026?
SIST EN IEC 60335-2-82:2026 is used by manufacturers and design engineers who build amusement machines and personal service machines, because it tells them what to design for before production starts. Test laboratories and certification bodies use it to run the required access, temperature, moisture, abnormal-operation and mechanical tests.
Quality managers and buyers use the standard to specify supplier expectations and to compare products against a common safety basis. Maintenance teams and installers use it because the document also addresses maintenance access, instructions, override keys, outdoor installation and water exposure.
It is also relevant to operators of commercial entertainment and self-service equipment who need to understand where the machine may be installed and what the instructions must say for safe use.
What changed in SIST EN IEC 60335-2-82:2026 from the previous edition?
SIST EN IEC 60335-2-82:2026 supersedes EN IEC 60335-2-82:2022 and EN IEC 60335-2-82:2022/A1:2025. The underlying IEC text, IEC 60335-2-82:2024, is described as a technical revision of the third edition and Amendment 1.
The stated technical changes are:
- alignment with IEC 60335-1:2020
- conversion of some notes to normative text in Clause 1, 19.2, 19.101 and 22.104
- introduction of test probe 18 in 22.101
- introduction of test probe 19 in 8.1.1 and 20.2
- addition of surface temperature-rise limits in 11.3, 11.8 and Table 101
Which standards are used with SIST EN IEC 60335-2-82:2026?
SIST EN IEC 60335-2-82:2026 is used with IEC 60335-1, which provides the general safety requirements that Part 2-82 supplements or modifies. The foreword also states that SIST EN IEC 60335-2-82:2026 is read in conjunction with SIST EN IEC 60335-2-82:2026/A11:2026.
The standard refers to these documents as part of its test and application framework:
- IEC 60065:2001, including AMD1:2005 and AMD2:2010, for lasers in Clause 32
- IEC 60068-2-52 for the salt mist test on outdoor appliances
- IEC 62368-1 for parts within its scope, and for audio amplifiers in normal operating conditions
- IEC 61032 for test probes 18, 19 and probe B
- Annexes B and R of IEC 60335-1, as modified here
What does the SIST EN IEC 60335-2-82:2026 document contain?
SIST EN IEC 60335-2-82:2026 contains the full clause structure for a Part 2 safety standard, from scope and normative references through construction, marking, testing and annexes. It includes test methods for normal operation, heating, moisture resistance, abnormal operation, stability, mechanical hazards and salt mist exposure.
The document also contains Figure 101, which shows the probe used for measuring surface temperatures, and Table 101, which gives the temperature-rise limits for different accessible surfaces and locations. Annex R adds software-evaluation rules for programmable electronic circuits, while Annex B adds battery-specific requirements and extra probe checks for low accessible parts.
Relations
- Effective Date
- 01-Nov-2026
- Effective Date
- 01-Nov-2026
- Effective Date
- 24-Mar-2026
- Effective Date
- 24-Mar-2026
- Effective Date
- 24-Mar-2026
- Refers
SIST EN 60065:2003/A1:2006 - Audio, video and similar electronic apparatus - Safety requirements - Effective Date
- 24-Mar-2026
- Effective Date
- 24-Mar-2026
- Effective Date
- 08-Sep-2026
- Effective Date
- 08-Sep-2026
- Effective Date
- 01-Nov-2026
Frequently Asked Questions
SIST EN IEC 60335-2-82:2026 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Household and similar electrical appliances - Safety - Part 2-82: Particular requirements for amusement machines and personal service machines (IEC 60335-2-82:2024)". This standard covers: This European standard deals with the safety of electric commercial amusement machines and personal service machines, their rated voltage being not more than 250 V for single-phase appliances and 480 V for other appliances, including direct current (DC) supplied appliances and battery-operated appliances
This European standard deals with the safety of electric commercial amusement machines and personal service machines, their rated voltage being not more than 250 V for single-phase appliances and 480 V for other appliances, including direct current (DC) supplied appliances and battery-operated appliances
SIST EN IEC 60335-2-82:2026 is classified under the following ICS (International Classification for Standards) categories: 97.180 - Miscellaneous domestic and commercial equipment; 97.200.40 - Playgrounds; 97.200.99 - Other equipment for entertainment; 97.220.99 - Other sports equipment and facilities. The ICS classification helps identify the subject area and facilitates finding related standards.
SIST EN IEC 60335-2-82:2026 has the following relationships with other standards: It is inter standard links to SIST EN IEC 60335-2-82:2022/A1:2025, SIST EN IEC 60335-2-82:2022, SIST EN IEC 62368-1:2024, SIST EN IEC 60068-2-52:2018, SIST EN 60065:2003/A2:2011, SIST EN 60065:2003/A1:2006, SIST EN 60065:2003, SIST EN 12976-1:2017, SIST EN 12976-1:2022, SIST EN IEC 60335-2-82:2026/A11:2026. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
SIST EN IEC 60335-2-82:2026 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
SLOVENSKI STANDARD
01-november-2026
Nadomešča:
SIST EN IEC 60335-2-82:2022
SIST EN IEC 60335-2-82:2022/A1:2025
Gospodinjski in podobni električni aparati - Varnost - 2-82. del: Posebne zahteve
za naprave za razvedrilo in naprave za storitvene dejavnosti (IEC 60335-2-82:2024)
Household and similar electrical appliances - Safety - Part 2-82: Particular requirements
for amusement machines and personal service machines (IEC 60335-2-82:2024)
Sicherheit elektrischer Geräte für den Hausgebrauch und ähnliche Zwecke - Teil 2-82:
Besondere Anforderungen für Dienstleistungs- und Unterhaltungsautomaten (IEC 60335
-2-82:2024)
Appareils électrodomestiques et analogues - Sécurité - Partie 2-82: Exigences
particulières pour les machines de divertissement et les machines de service pour les
personnes (IEC 60335-2-82:2024)
Ta slovenski standard je istoveten z: EN IEC 60335-2-82:2026
ICS:
97.180 Razna oprema za dom in Miscellaneous domestic and
trgovino commercial equipment
97.200.99 Druga oprema za razvedrilo Other equipment for
entertainment
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EUROPEAN STANDARD EN IEC 60335-2-82
NORME EUROPÉENNE
EUROPÄISCHE NORM September 2026
ICS 97.180; 97.200.40 Supersedes EN IEC 60335-2-82:2022; EN IEC 60335-2-
82:2022/A1:2025
English Version
Household and similar electrical appliances - Safety - Part 2-82:
Particular requirements for amusement machines and personal
service machines
(IEC 60335-2-82:2024)
Appareils électrodomestiques et analogues - Sécurité - Sicherheit elektrischer Geräte für den Hausgebrauch und
Partie 2-82: Exigences particulières pour les machines de ähnliche Zwecke - Teil 2-82: Besondere Anforderungen für
divertissement et les machines de service pour les Dienstleistungs- und Unterhaltungsautomaten
personnes (IEC 60335-2-82:2024)
(IEC 60335-2-82:2024)
This European Standard was approved by CENELEC on 2026-07-27. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Türkiye and the United Kingdom.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2026 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN IEC 60335-2-82:2026 E
European foreword
This document (EN IEC 60335-2-82:2026) consists of the text of document IEC 60335-2-82:2024,
prepared by IEC/TC 61 "Safety of household and similar electrical appliances".
The following dates are fixed:
• latest date by which this document has to be (dop) 2027-09-30
implemented at national level by publication of an
identical national standard or by endorsement
• latest date by which the national standards (dow) 2029-09-30
conflicting with this document have to be withdrawn
This document supersedes EN IEC 60335-2-82:2022 and all of its amendments and corrigenda (if any).
This document is read in conjunction with EN IEC 60335-2-82:2026/A11:2026.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
Endorsement notice
The text of the International Standard IEC 60335-2-82:2024 was approved by CENELEC as a European
Standard without any modification.
IEC 60335-2-82 ®
Edition 4.0 2024-10
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Household and similar electrical appliances – Safety –
Part 2-82: Particular requirements for amusement machines and personal
service machines
Appareils électrodomestiques et analogues – Sécurité –
Partie 2-82: Exigences particulières pour les machines de divertissement et les
machines de service pour les personnes
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
INTERNATIONALE
ICS 97.180, 97.200.40 ISBN 978-2-8322-9688-2
– 2 – IEC 60335-2-82:2024 © IEC 2024
CONTENTS
FOREWORD . 4
INTRODUCTION . 7
1 Scope . 8
2 Normative references . 9
3 Terms and definitions . 9
4 General requirement . 11
5 General conditions for the tests . 11
6 Classification . 12
7 Marking and instructions . 12
8 Protection against access to live parts . 13
9 Starting of motor-operated appliances . 14
10 Power input and current . 14
11 Heating . 14
12 Charging of metal-ion batteries . 15
13 Leakage current and electric strength at operating temperature . 15
14 Transient overvoltages . 15
15 Moisture resistance . 15
16 Leakage current and electric strength . 16
17 Overload protection of transformers and associated circuits . 16
18 Endurance . 16
19 Abnormal operation . 16
20 Stability and mechanical hazards . 18
21 Mechanical strength . 19
22 Construction . 19
23 Internal wiring . 20
24 Components . 21
25 Supply connection and external flexible cords . 21
26 Terminals for external conductors . 22
27 Provision for earthing . 22
28 Screws and connections . 22
29 Clearances, creepage distances and solid insulation . 22
30 Resistance to heat and fire . 22
31 Resistance to rusting . 23
32 Radiation, toxicity and similar hazards . 23
Annexes . 24
Annex B (normative) Battery-operated appliances, separable batteries and detachable
batteries for battery-operated appliances . 25
Annex R (normative) Software evaluation . 26
Bibliography . 27
Figure 101 – Probe for measuring surface temperatures . 23
IEC 60335-2-82:2024 © IEC 2024 – 3 –
Table 101 – Maximum temperature rises for specified external accessible surfaces
under normal operating conditions . 15
– 4 – IEC 60335-2-82:2024 © IEC 2024
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
HOUSEHOLD AND SIMILAR ELECTRICAL APPLIANCES –
SAFETY –
Part 2-82: Particular requirements for amusement machines and
personal service machines
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international
co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and
in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as "IEC Publication(s)"). Their
preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with
may participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) IEC draws attention to the possibility that the implementation of this document may involve the use of (a)
patent(s). IEC takes no position concerning the evidence, validity or applicability of any claimed patent rights in
respect thereof. As of the date of publication of this document, IEC had not received notice of (a) patent(s), which
may be required to implement this document. However, implementers are cautioned that this may not represent
the latest information, which may be obtained from the patent database available at https://patents.iec.ch. IEC
shall not be held responsible for identifying any or all such patent rights.
IEC 60335-2-82 has been prepared by IEC technical committee 61: Safety of household and
similar electrical appliances. It is an International Standard.
This fourth edition cancels and replaces the third edition published in 2017 and
Amendment 1:2020. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
a) alignment with IEC 60335-1:2020;
b) conversion of some notes to normative text (Clause 1, 19.2, 19.101, 22.104);
c) introduction of test probe 18 (22.101);
IEC 60335-2-82:2024 © IEC 2024 – 5 –
d) introduction of test probe 19 (8.1.1, 20.2);
e) addition of surface temperature rise limits (11.3, 11.8, Table 101).
The text of this International Standard is based on the following documents:
Draft Report on voting
61/7273/FDIS 61/7299/RVD
Full information on the voting for its approval can be found in the report on voting indicated in
the above table.
The language used for the development of this International Standard is English.
This document was drafted in accordance with ISO/IEC Directives, Part 2, and developed in
accordance with ISO/IEC Directives, Part 1 and ISO/IEC Directives, IEC Supplement, available
at www.iec.ch/members_experts/refdocs. The main document types developed by IEC are
described in greater detail at www.iec.ch/publications.
A list of all parts of the IEC 60335 series, under the general title: Household and similar
electrical appliances – Safety, can be found on the IEC website.
This part 2 is to be used in conjunction with the latest edition of IEC 60335-1 and its
amendments unless that edition precludes it; in that case, the latest edition that does not
preclude it is used. It was established on the basis of the sixth edition (2020) of that standard.
NOTE 1 When "Part 1" is mentioned in this standard, it refers to IEC 60335-1.
This part 2 supplements or modifies the corresponding clauses in IEC 60335-1, so as to convert
that publication into the IEC standard: Particular requirements for amusement machines and
personal service machines.
When a particular subclause of Part 1 is not mentioned in this part 2, that subclause applies as
far as is reasonable. When this standard states "addition", "modification" or "replacement", the
relevant text in Part 1 is to be adapted accordingly.
NOTE 2 The following numbering system is used:
– subclauses, tables and figures that are numbered starting from 101 are additional to those in Part 1;
– unless notes are in a new subclause or involve notes in Part 1, they are numbered starting from 101, including
those in a replaced clause or subclause;
– additional annexes are lettered AA, BB, etc.
NOTE 3 The following print types are used:
– requirements: in roman type;
– test specifications: in italic type;
– notes: in small roman type.
Words in bold in the text are defined in Clause 3. When a definition concerns an adjective, the adjective and the
associated noun are also in bold.
– 6 – IEC 60335-2-82:2024 © IEC 2024
The committee has decided that the contents of this document will remain unchanged until the
stability date indicated on the IEC website under webstore.iec.ch in the data related to the
specific document. At this date, the document will be
• reconfirmed,
• withdrawn, or
• revised.
NOTE 4 The attention of National Committees is drawn to the fact that equipment manufacturers and testing
organizations can need a transitional period following publication of a new, amended or revised IEC publication in
which to make products in accordance with the new requirements and to equip themselves for conducting new or
revised tests.
It is the recommendation of the committee that the content of this publication be adopted for implementation nationally
not earlier than 12 months or later than 36 months from the date of publication.
IEC 60335-2-82:2024 © IEC 2024 – 7 –
INTRODUCTION
It has been assumed in the drafting of this International Standard that the execution of its
provisions is entrusted to appropriately qualified and experienced persons.
Guidance documents concerning the application of the safety requirements for appliances can
be accessed via TC 61 supporting documents on the IEC website
https://www.iec.ch/tc61/supportingdocuments
This information is given for the convenience of users of this International Standard and does
not constitute a replacement for the normative text in this standard.
This standard recognizes the internationally accepted level of protection against hazards such
as electrical, mechanical, thermal, fire and radiation of appliances when operated as in normal
use taking into account the manufacturer's instructions. It also covers abnormal situations that
can be expected in practice and takes into account the way in which electromagnetic
phenomena can affect the safe operation of appliances.
This standard takes into account the requirements of IEC 60364 as far as possible so that there
is compatibility with the wiring rules when the appliance is connected to the supply mains.
However, national wiring rules can differ.
If an appliance within the scope of this standard also incorporates functions that are covered
by another part 2 of IEC 60335, the relevant part 2 is applied to each function separately, as
far as is reasonable. If applicable, the influence of one function on the other is taken into
account.
When a part 2 standard does not include additional requirements to cover hazards dealt with in
Part 1, Part 1 applies.
NOTE 1 This means that the technical committees responsible for the part 2 standards have determined that it is
not necessary to specify particular requirements for the appliance in question over and above the general
requirements.
This standard is a product family standard dealing with the safety of appliances and takes
precedence over horizontal and generic standards covering the same subject.
NOTE 2 Horizontal publications, basic safety publications and group safety publications covering a hazard are not
applicable since they have been taken into consideration when developing the general and particular requirements
for the IEC 60335 series of standards.
An appliance that complies with the text of this standard will not necessarily be considered to
comply with the safety principles of the standard if, when examined and tested, it is found to
have other features that impair the level of safety covered by these requirements.
An appliance employing materials or having forms of construction differing from those detailed
in the requirements of this standard may be examined and tested according to the intent of the
requirements and, if found to be substantially equivalent, may be considered to comply with the
standard.
NOTE 3 Standards dealing with non-safety aspects of household appliances are:
– IEC standards published by TC 59 concerning methods of measuring performance;
– CISPR 11, CISPR 14-1 and relevant IEC 61000-3 series standards concerning electromagnetic emissions;
– CISPR 14-2 concerning electromagnetic immunity;
– IEC standards published by TC 111 concerning environmental matters.
– 8 – IEC 60335-2-82:2024 © IEC 2024
HOUSEHOLD AND SIMILAR ELECTRICAL APPLIANCES –
SAFETY –
Part 2-82: Particular requirements for amusement machines and
personal service machines
1 Scope
This clause of Part 1 is replaced by the following.
This part of IEC 60335 deals with the safety of electric commercial amusement machines and
personal service machines, their rated voltage being not more than 250 V for single-phase
appliances and 480 V for other appliances, including direct current (DC) supplied appliances
and battery-operated appliances.
Examples of appliances that are within the scope of this standard are
– amusement machines:
• billiard tables;
• bowling machines;
• dartboards;
• driving simulators;
• gaming machines;
• kiddie rides;
• laser shooting appliances;
• pinball machines;
• video games;
– personal service machines:
• card re-value machines;
• currency dispensers;
• luggage lockers;
• weighing machines;
• shoe shining appliances.
As far as is practicable, this standard deals with the common hazards presented by appliances
that are encountered by users and maintenance persons.
Attention is drawn to the fact that
– for appliances intended to be used in vehicles or on board ships or aircraft, additional
requirements can be necessary;
– in many countries, additional requirements are specified by the national authorities
responsible for health, for the protection of labour and similar authorities.
IEC 60335-2-82:2024 © IEC 2024 – 9 –
This standard does not apply to
– appliances intended exclusively for household use;
– appliances intended exclusively for industrial purposes;
– appliances intended to be used in locations where special conditions prevail, such as the
presence of a corrosive or explosive atmosphere (dust, vapour or gas);
– appliances for washing cars;
– dispensing appliances and vending machines (IEC 60335-2-75);
– appliances within the scope of IEC 62368-1, such as jukeboxes, household video games,
copying machines, ticket machines and automatic teller machines;
– appliances intended to be used when a trained attendant is present, such as virtual reality
systems;
– equipment intended exclusively for fairgrounds, such as carousels;
– self-balancing personal transport devices (IEC 60335-2-114).
2 Normative references
This clause of Part 1 is applicable except as follows.
Addition:
IEC 60065:2001 , Audio, video and similar electronic apparatus – Safety requirements
IEC 60065:2001/AMD1:2005
IEC 60065:2001/AMD2:2010
IEC 60068-2-52, Environmental testing – Part 2: Tests – Test Kb: Salt mist, cyclic (sodium,
chloride solution)
IEC 62368-1 Audio/video, information and communication technology equipment – Part 1:
Safety requirements
3 Terms and definitions
This clause of Part 1 is applicable except as follows.
3.1 Definitions relating to physical characteristics
3.1.9 Modification:
normal operation
Replace the first paragraph with the following:
operation of the appliance under the following conditions:
The appliance is operated in the ready mode until steady conditions are established and then
under the most unfavourable conditions of normal use.
The appliance is refilled when necessary in accordance with the instructions for use, or the
instructions for maintenance, and the next operating period started as soon as possible.
___________
There exists a consolidated edition 7.2 (2010) that includes edition 7 and its Amendment 1 and Amendment 2.
This publication has been withdrawn.
– 10 – IEC 60335-2-82:2024 © IEC 2024
Appliances that support persons in normal use are loaded as follows:
– kiddie rides, 50 kg for each riding position;
– other appliances, 100 kg for the first riding position and 75 kg for each additional riding
position.
Note 101 to entry: The riding position can be for a sitting or standing person.
If the instructions state that higher loads are allowed, the appliance is loaded accordingly.
Audio amplifiers are operated in accordance with the normal operating conditions specified in
IEC 62368-1.
3.5 Definitions relating to types of appliances
3.5.101
kiddie ride
moving appliance having a stationary base for use by one or two children between the ages of
three and ten years, under the supervision of an adult
3.6 Definitions relating to parts of appliances
3.6.2 Replacement:
detachable part
part that can be removed without the aid of a tool, part that is removed in accordance with the
instructions for use or instructions for maintenance, even if a tool or access key is necessary
for removal, or part that does not fulfil the test of 22.11
Note 1 to entry: If a part has to be removed for installation purposes, this part is not considered to be detachable
even if the instructions state that it is to be removed.
Note 2 to entry: A part that can be opened is considered to be a part that can be removed.
3.6.101
access key
key or other means that gives access to the maintenance area but does not give access to the
service area
Note 1 to entry: "Other means" includes a tool or operation by codes or signals produced by optical or
electromagnetic sources.
3.6.102
override key
key or other means that is used to render an interlock inoperative
3.6.103
user area
area where access is gained without the use of an access key or a tool
3.6.104
maintenance area
area where access can only be gained by the use of an access key
3.6.105
service area
area where access cannot be gained by the use of an access key alone
IEC 60335-2-82:2024 © IEC 2024 – 11 –
3.7 Definitions relating to safety components
3.7.3 Replacement:
thermal cut-out
device that during abnormal operation limits the temperature of the control
...
