Secondary cells and batteries - Marking symbols for identification of their chemistry

This document specifies methods for the clear identification of secondary cells, batteries,
battery modules and monoblocs according to their chemistry (electrochemical storage
technology).
The markings described in this document are applicable for secondary cells, batteries, battery
modules and monoblocs with a volume of more than 900 cm3.
The marking of the chemistry is useful for the installation, operation and decommissioning
phases of battery life.
Many recycling processes are chemistry specific, thus undesired events can occur when a
battery which is not of the appropriate chemistry enters a given recycling process. In order to
ensure safe handling during sorting and recycling processes, therefore, the battery is marked
so as to identify its chemistry.
This document defines the conditions of utilization of the markings indicating the chemistry of
these secondary batteries.
The details of markings and their application are defined in this document.
NOTE Nothing in this document precludes the marking of batteries with recycling and chemistry symbols required
by state, federal, national or regional laws or regulations or with a seal under license by a national recycling
program.
